12 Tooth 5mm Pitch GT2 Pulley

Used with the Intake Kit to create various intake system with various lengths.

• ID: 6mm
• OD: 10mm
• 1000mm long
• Wall Thickness: 2mm
• Flexible
• Bend Radius: ~30mm
• Silicone
• Durometer: 70A
• Black
• Step File

64 Tooth 5mm Pitch GT2
Belt 9mm wide
Rubber

Black

• 82 Tooth 5mm Pitch GT2
• Belt 9mm wide
• Rubber
• Black

• GT2 Pulley
• Φ41.2mm*13.0mm thick
• M3 pass through holes SHCS should
• sit flush
• Bearing hole, the bearing should
• AL6061-T6
• Step File

The Intake Kit can be used to create intake systems and is ideal for the FIRST Technical Challenge (FTC) and World Robotics Olympiad (WRO). Used with the Silicone Rubber Tubing #76410

Specifications:

• Main piece
  • hex width: 20.78mm*10.0mm thick
  • 6*M6 tapped holes
  • 1*M4 tappped hole for M4 set screw
  • 6.0mm Diameter D Hole
  • Material AL6061-T6
  • Φ7.5mm*14.0mm
• Pins
  • 6PCS in a pack
  • M6*4.0mm thread
  • Material SS303
• Step file

• Φ29.0mm*16.0mm thick
• 6*M3 thread tapping through (including 2*M3 thread for M3 SHCS)
• Φ6.0mm D hole
• AL6061-T6
• Step File

Made of aluminum, the Studica Clamping 6mm D-Shaft Hub is used with flex and drive wheels

Specifcation:

• Material: 6061-T6 Aluminum
• 6mm ID
• Hole pattern for connecting to structure
• Step File
