The Autonomous Mobile Robotics Workshop Kit is used in the classroom for teaching, testing and doing research in Autonomous Mobile Robotics. It also includes each of the essential components referenced in the WorldSkills Mobile Robotics training material.

• Parts List (PDF)

The FTC Drive Base Kit  is available for FIRST teams only. This special offer is only available for a limited time and to qualify you must provide us with your FTC team name and number. This drive base kit when purchased individually is valued at $389USD.

Includes,

• 2 - 432mm U-Channel  76010
• 2 - 192mm U-Channel  76015
• 4 - Motor Mount Plate  76140
• 2 - End Piece Plate (2pak)  76143-2
• 1 - 6mm x 96mm D-Shaft (2 pack)  76161-6
• 2 - M3 x 10mm Button Head Cap Screw (pack of 50)  76203-50
• 4 - 30 Tooth Bevel Gear (2 Pack)  76219-2
• 1 - Flange Bearing 6mm ID, 14mm OD, 15mm Flange (12 pack)  76302-12
• 1 - Collar 6mm ID D-Shaft, 12mm OD (6 pack)  76304-6
• 1 - Shaft Spacer Plastic 6mm ID x 10mm OD x 1mm L (24 pack)  76305-24
• 1 - Mecanum Wheel B Set (2 left, 2 right, 100mm, Bearings, w/6mm Hub)  76243

Note: You can use any FIRST legal motor with this set.

The Titan Quad Motor Controller is a powerful, 4-channel CAN-based motor controller with a built-in fuse-box (for DC motors up to 20A).

Features:

• 4 x Hardware encoder ports – one for each motor
• 2 limit switch ports for each motor
• Fuse box to set manual current limits
• 2x Power extension ports to power other 12VDC devices. I.E.
  • VMX Robotics Controller
  • Servo Power Module
• Built in LED Controller
• 6A power supply for LED’s
• i2c communication port to control LED Controller
• USB ports are updated to USB-C to better support todays cable standards
• Step File


The Studica VMX is a powerful robot controller,

• Enables Tele-op and autonomous control
• Programmable in Java, C++, Python, LabVIEW, and ROS
• Integrates the navX-IMU, a Linux based controller, Gigabit Ethernet, USB3 ports and built-in Wifi/Bluetooth.
• Can be used an a Robot Control System or Vision/Motion processor
• Supports Open CV, Tensor Flow, SLAM (Simultaneous Localization and Mapping
• Step File

The Studica VMX leverages five recent key technology developments,

• Highly-integrated, inexpensive, WiFi-enabled, multi-core Linux computing platform with lots of USB IO for expansion
• 32-bit ARM Microcontrollers incorporating sophisticated I/O and digital communications engines
• Low-cost MEMs Inertial Measurement Units (IMUs)
• Powerful software providing rich libraries and tools for developing robot software in C++, Java
• CAN bus for high-speed, real-time communication between devices

The Studica VMX Technology Enables,

• Far richer development environments and tools
  • Because VMX is much more than a robot controller – it is a powerful, Linux-based   desktop computing platform with network/monitor/keyboard/mouse support.
• Very powerful software features
  • State-of-the-art software development GUIs (e.g., VS Code) libraries and tools (drive-  train kinematics, path-planning, vision processing, autonomous navigation,   performance data acquisition/playback)
• Access to cutting-edge sensors (for use outside the competition)
  • VMX’s multitude of modern digital communications interfaces and Linux-based   operating system allow users to directly access most modern devices (e.g., Intel   RealSense tracking and depth cameras and LIDAR

New for the 2022-2023 Season

Download the Kit List here.


FTC Teams are eligible to get 1 kit at a heavily discounted price. To apply for the discount please fill out this application form.

The FTC Drive Base Kit v2 (70400-v2) is available for FIRST teams only and is fully FIRST legal. This is an upgrade from our first version (part # 70400). It includes our new slim mecanum wheels with bearings on all rollers, allowing you to make a wider base robot. It also has 4 NeveRest Orbital 20 Gearmotors with wires, our new Clamping Shaft Hubs, 4 bumpers and more hardware.
