ThePowerpole Crimp Tool 15, 30, 45 crimping tool provides a positive crimp on the 15, 30 & 45 amp contacts manufactured by Anderson Power Products for the Powerpole® line of products. It has the following features.

Specifications:

• Crimps all three sizes of Powerpole® contacts; 15, 30 and 45 amp
• Built-in contact positioner that holds the contact during crimping
• Ratchet mechanism assures proper crimps every time
• Far faster and better than soldering
• Provides the highest strength and the lowest resistance connections possible
• Dimensions: 7.75" X 3" X 1.5"
• Weight: 20 ounces
• High Contact retention force

Contacts & Jaw Position

The 3 contacts have different amp ratings:

• 15 Amp (SKU: 1332) is designed to receive 16, 18 and 20 gauge wire.
• 30 Amp (SKU: 1331) is designed to receive 12, 14 gauge wire.
• 45 Amp (SKU: 261G2) is designed to receive 10 gauge wire.

The contact size corresponds to the position marking on the die. The 15 amp contact goes into the 15 amp position, the 30 amp into the 30 position, and 45 amp into the 45 position.

Assembly Instructions 15 & 30 Amp

To crimp the 15 & 30 amp contacts it is recommended that you insert the wire into the contact prior to inserting them into the tool. Then, with the flat side of the contact down, insert the contact tip into the proper slot for crimping.

Squeeze the ratchet handle until the ratchet mechanism releases. Do not over crimp by squeezing the handles together until they touch, it is possible to break the die.

Assembly Instructions 45 Amp

To crimp the 45 amp contact it is recommended that you position the tip of the 45 amp contact into the 45 amp position slot before the wire is inserted. Make sure the contact is properly positioned with the U (open contact) facing up. If the contact is lying sideways you may not obtain a proper crimp. Then, insert your wire into the inserted contact.

Squeeze the ratchet handle until the ratchet mechanism releases. Do not over crimp by squeezing the handles together until they touch, it is possible to break the die.

Read more: http://www.powerwerx.com/crimping-tools/tricrimp-crimping-powerpole-contacts.html#ixzz2YlrFRGU8

Note: Only official tooling solutions recommended by APP may be acceptable for safety agency approvals such as UL, CSA and TUV. Official tooling solutions such as the 1309 series are available for purchase at a higher price. Read more: http://www.powerwerx.com/crimping-tools/tricrimp-crimping-powerpole-contacts.html#ixzz44INkWK9m

This kit includes the tools need to cut and join a urethane belt. Recommended for the 5mm Urethane Round Belt - part # 76400

This kit includes the tools need to cut and join a urethane belt. Recommended for the 5mm Urethane Round Belt - part # 76400

The M3 T-Slot Nut 100 pack, is a Hammer Head Series 20 and is used with any M3 screw and fits the Studica T-Slot Extrusions.

Standoffs can be used to space parallel plates, channel, brackets, etc.

Specifications:

• Material: 6061-T6 Aluminum
• Thread: M3
• Length: 52mm
• Step File

Standoffs can be used to space parallel plates, channel, brackets, etc.

Specifications:

• Material: 6061-T6 Aluminum
• Thread: M3
• Length: 42mm
• Step File

M3 x 30mm Socket Head Cap Screw (pack of 50), Zinc Plated.

• Step File

• Step File

M3 x 8mm Socket Head Cap Screw (pack of 100), Zinc Plated.

• Step File

This 5.5mm Combination Wrench ships with most of our kits works with all the M3 nuts available on our store.

This Hex Ball End Screwdriver can be used with most of the M3 screws.

Includes 6 bits,

• Slotted 3.3
• Phillips: OHO
• Hex 1/16inch
• Hex 3/32inch
• Hex 7/64inch

Has two compartments on the lid for tools and electronics.

• Material: PP
• Size: 59*36*32cm (23" x 14" x 12.6")
• Capacity: 55L

Standoffs can be used to space parallel plates, channel, brackets, etc.

Specifications:

• Material: 6061-T6 Aluminum
• Thread: M3
• Length: 25mm
• Step File

Rubber Grommets are made for the Studica channel and plates and or any structure with a 14mm hole. Use it for protecting wire or as a bumper.

Specifications:

• Outside diameter: 18mm
• Inside Diameter : 11mm
• Hole fitting diameter: 14mm
• Thickness: 9mm
• Step File

The Studica U-Channel Bumper is connected to the end of the Studica 48mm U-Channel and helps remove sharp corners that can cause damage when the robot is bumping into other objects. It also creates an ecstatically clean finish to your robot.

Specifications:

• Material: Silicomn/Rubber
• Hardness: 50-60 Shore A
• Length: 48mm
• Width: 48mm
• Thickness: 10.75mm
• Color: Black
• Step File

The M3 x 10mm Low Profile Screw has a Countersunk Hex Socket Flat Head with a matching Kep Nut. This set is made for the Slide Rail, 288mm Length, 180mm Stroke and the Slide Rail, 384mm Length, 240mm Stroke

Includes,

• 6 - M3 x 10mm Low Profile Screw
  • 304 Stainless Steel
  • M3
  • Din 7991
  • Counter sunk hex flat head
• 6 - Kep nut
  • M3
  • 304 Stainless Steel Base
  • 420 Stainless Steel Crown

M3 x 6mm Socket Head Cap Screw (pack of 50), Zinc Plated.

Step file

IWS-2820M open barrel crimper tool is designed to crimp non-insulated open barrel, OEM-style terminals. Perfect for servo lead connectors and some other RC crimp connectors.

Standoffs can be used to space parallel plates, channel, brackets, etc.

Specifications:

• Material: 6061-T6 Aluminum
• Thread: M3
• Length: 25mm
• Step File

Standoffs can be used to space parallel plates, channel, brackets, etc.

Specifications:

• Material: 6061-T6 Aluminum
• Thread: M3
• Length: 48mm
• Step File

M3 x 20mm Socket Head Cap Screw (pack of 50), Zinc Plated.

• Step File

• Step File

M3 x 10mm Button Head Cap Screw (pack of 50), Zinc Plated.

• Step File

M3 x 12mm Socket Head Cap Screw (pack of 100), Zinc Plated.

• Step File

M3 x 10mm Socket Head Cap Screw (pack of 100), Zinc Plated.

• Step File

The easy way to change the length of your #25 chain. (Chain not included)

- See Instructions for use

Specifications:

• 7 color pcs
• 1.5, 2, 2.5, 3, 4, 5, 6
• Non-slip handle
• ball-end and straight-end
• S2 Hardness
• Non-corrosive
• Weight: 0.118kg

Made of Nylon, the Studica Rubber Foot is used with the Studica Robotics building structure and for many other uses.

Specifications:

• Material: Nylon
• Outside OD: 24mm
• Inner OD: 21mm
• Height: 24mm
• Step File

• For 5.5mm nuts
• CRV material
• heat treatment
• surface matt chrome plated
• 100mm exposure shank
• socket head cold heading treatment

• Used with 5.5mm Nuts
• 50BV30 ratchet head
• heat treatment
• surface balck finished
• body #45 carbon steel material
• mirror polishing
• product engrave size and laser logo
• length 110mm
