Urethane Belt Joining Kit - 110V

Includes 6 bits,

• Slotted 3.3
• Phillips: OHO
• Hex 1/16inch
• Hex 3/32inch
• Hex 7/64inch

The 6mm diameter D -Shaft is made of stainless steel and is used throughout our building system as drive components. The D-Shaft profile is used with pulleys, gears and hubs when tightening the set screws and creating a non-slip connection.

Specifcation:

• Stainless Steel
• 140mm length
• 6mm OD
• 5.5mm to flat
• Step File

The 75mm Drive Wheel can be used as a simple wheel providing good traction on carpet and tile flooring. They can also be used for intake systems.

Use with 1/2" hex shaft of use 6mm Shaft Hub to use connect 6mm D-Shaft Axles.

Specifications:

• Diameter:   75mm
• Axial width:  12.5mm
• Hub:  1/2" Inner Hex
• Inner Material: Molded Plastic in Yellow
• Outer Material: TPU Polyurethane in Black
• Outer Material Durometer: 60A
• Weight: 0.05kg
• Step File

The Rack & Pinion Linear Slide Set (2 pack) includes 2 Racks, 2 Pinions, and 4 Glides. The rack hole pattern matches that of the channel, flat beams, square beams and flat brackets so it's easy to mount on the Studica structure.  the rack and the glides are made of POM Plastic providing high stiffness, low friction, and excellent dimensional stability. The pinion has a 6mm D-shaft hub, 25.52mm addendum circle diameter and is made of 6061-T6 Aluminum.

• Step File

The 110mm All-Terrain Wheel w/6mm Adapter has a foam core and therefore does not require air. They grip well on hard smooth surfaces and are perfect for travel on un-even surfaces where you may have mulch, sand, dirt, or gravel. They are designed and manufactured by Studica to work with the Studica Robotics Building platform and will also work with other building sets.

Specifications:

• Diameter: 110mm
• Width: 45mm
• Inner diameter of wheel frame: 75mm
• Hexagon connector: 12mm
• Unit weight: 128g
• 6mm axle adopter

Studica 100mm Aluminum Mecanum Wheel Left and Right Slant w/6mm Hub and  steel ball bearings. With blue aluminium frame and yellow rollers.  Wheel comprised of 9 yellow rollers is able to move in any direction. Rollers are set at 45° to the axis of rotation of the wheel.  Rollers are mounted with steel ball bearings,making roll more fluent.

 Wheel Specifications:

• Diameter:                                                100mm
• Width:                                                       50m
• Number of Rollers:                                 9
• Number of Plates each wheel:             2
• Body material:                                        Aluminium alloy
• Roller material:                                       Polyethylene (PE) and Polypropylene (PP)
• Spacer Material:                                     Nylon
• Length of roller:                                     19mm
• Weight:                                                    354gm

Hub Specifications:

• Inside Diameter:                                    6mm
• Outside Diameter :                                22mm
• Bore Length:                                          15mm
• Weight:                                                   32g

Studica 100mm Aluminum Mecanum Wheel Left and Right Slant w/6mm Hub and  steel ball bearings. With blue aluminium frame and yellow rollers.  Wheel comprised of 9 yellow rollers is able to move in any direction. Rollers are set at 45° to the axis of rotation of the wheel.  Rollers are mounted with steel ball bearings,making roll more fluent.

 Wheel Specifications:

• Diameter:                                                100mm
• Width:                                                       50m
• Number of Rollers:                                 9
• Number of Plates each wheel:             2
• Body material:                                        Aluminium alloy
• Roller material:                                       Polyethylene (PE) and Polypropylene (PP)
• Spacer Material:                                     Nylon
• Length of roller:                                     19mm
• Weight:                                                    354gm

Hub Specifications:

• Inside Diameter:                                    6mm
• Outside Diameter :                                22mm
• Bore Length:                                          15mm
• Weight:                                                   32g
