CubeNode 2xCAN Eth NO IMU

The CubeNode 2xCAN Eth NO IMU is a specialized version of the CubePilot development platform designed without an integrated Inertial Measurement Unit (IMU). It serves as a modular networking and communication hub for drone and robotics systems, providing high-speed Ethernet and CAN connectivity to flight controllers

MFR Part #: CP-06313-1110

$49.20

Qty:

Specifications

Core Specifications

Processor: Dual-core architecture featuring an Arm® Cortex®-M7 (up to 480 MHz) and a Cortex®-M4 (up to 240 MHz).
Memory: 2 Mbytes dual-bank Flash and up to 1 Mbyte RAM (including 192 Kbytes TCM RAM and 864 Kbytes user SRAM).
Connectivity:
- 2x CAN Bus: Dual high-speed CAN interfaces for connecting sensors and peripherals.
- Ethernet (Eth): Provides networking capabilities via the PPP protocol, enabling up to 12Mbit/s links for transporting MAVLink and CAN data.
- No IMU: This specific model excludes the optional three-axis gyroscope/accelerometer found in other variants (like the CP-06313-1111), making it suitable for applications where motion sensing is handled by a separate external flight controller or is not required.

Key Functions & Features

Peripheral Gateway: Often functions as a DroneCAN (UAVCAN) gateway, allowing ArduPilot-based flight controllers to communicate with Ethernet-based networks.
Networking Hub: Bridges Cube flight controllers (like Cube Orange+ or Cube Red) that lack native Ethernet to external network infrastructures.
Development Platform: Used to refine navigation systems, payloads, and communication modules.

Software Compatibility: Supported by ArduPilot (v4.5+) and standard DroneCAN GUI tools for firmware updates and parameter configuration

Core Specifications

Processor: Dual-core architecture featuring an Arm® Cortex®-M7 (up to 480 MHz) and a Cortex®-M4 (up to 240 MHz).
Memory: 2 Mbytes dual-bank Flash and up to 1 Mbyte RAM (including 192 Kbytes TCM RAM and 864 Kbytes user SRAM).
Connectivity:
- 2x CAN Bus: Dual high-speed CAN interfaces for connecting sensors and peripherals.
- Ethernet (Eth): Provides networking capabilities via the PPP protocol, enabling up to 12Mbit/s links for transporting MAVLink and CAN data.
- No IMU: This specific model excludes the optional three-axis gyroscope/accelerometer found in other variants (like the CP-06313-1111), making it suitable for applications where motion sensing is handled by a separate external flight controller or is not required.

Key Functions & Features

Peripheral Gateway: Often functions as a DroneCAN (UAVCAN) gateway, allowing ArduPilot-based flight controllers to communicate with Ethernet-based networks.
Networking Hub: Bridges Cube flight controllers (like Cube Orange+ or Cube Red) that lack native Ethernet to external network infrastructures.
Development Platform: Used to refine navigation systems, payloads, and communication modules.

Software Compatibility: Supported by ArduPilot (v4.5+) and standard DroneCAN GUI tools for firmware updates and parameter configuration
