First Person View Kit - FPV2

The WorldSkills 2022 Mobile Robotics Collection by Studica is the authorized collection for the WorldSkills Mobile Robotics Competition that was used in Bordeaux, France. Featuring the Studica VMX Robotics Controller for WorldSkills, the Titan Quad Motor Controller and Servo Power Block. This comprehensive Collection also includes electronics, accessories, motors, servos, mounts, U-Channel, mounting plates, flat brackets, irregular brackets, and flat beams. You'll also find gears, sprockets, pulleys, belts, axles, slides, rack & pinion, wheels, bushings, bearings, coupling, collars, spacers, screws, nuts, and standoffs.


Includes Everything You Need (Over 1500 components).


Download BOM

The Ultrasonic Distance Sensor Bracket is used to secure the Ultrasonic Distance Sensor to the Studica channel.

• Step File

The WorldSkills Lyon 2024 Autonomous Mobile Robotics Collection, by Studica, is the authorized collection for the WorldSkills Autonomous Mobile Robotics Competition in Lyon, France, 10-15 September 2024. This collection includes most of the items in the previous competition collection and has 28 new parts. The biggest change is the new 3D Depth Camera, the 360 Degree LiDAR which will bring the competition to the next level for Autonomous Mobile Robotics (AMR).

The collection includes everything you will need to complete a full functioning robot that will be able to compete at Lyon 2024. As in the previous, you will be allowed to create 3D printed parts to make any additional parts needed. Includes the VMX Robotics Controller, which can be programmed in Java, C++, Python, ROS, and LabVIEW. This collection also includes electronics, accessories, motors, servos, mounts, U-Channel, mounting plates, flat brackets, irregular brackets, and flat beams. You'll also find gears, sprockets, pulleys, belts, axles, slides, rack & pinion, wheels, bushings, bearings, coupling, collars, spacers, screws, nuts, and standoffs. (Over 1600 components).

If you already have the 2022 Shanghai/Bordeaux Collection and wish to add only the new items, you can purchase the Lyon 2024 Upgrade Kit

Download the complete BOM and getting starting guide

Download the Lyon Apple Tree CAD file

The Cobra Line Follower Array provides 4 X QRE1113 IR reflectance sensor mounted on a 9mm pitch Each sensor is comprised of two parts - an IR emitting LED and an IR sensitive phototransistor. When you apply power to the VCC and GND pins the IR LED inside the sensor will illuminate.

The Studica Line Sensor Board consists of 4 IR LED/phototransistor pairs, making it a great detector for a line-following robot.  The Line Sensor Board allows the robot to tell objects or surfaces apart based on how dark or light they are. It shines a beam of infrared light out onto the object, and measures how much light is reflected back.

Each sensor provides a separate analog voltage output. The sensor board is an infrared emitter/receiver that is able to differentiate between a dark surface (with low IR reflectivity – 3.3V to 5V) and a light surface (with high IR reflectivity – 0V to 0.5V). However, this range can vary depended on the installed height of the sensor board.

The optimum height distance is 3-5 mm; however, the reflectivity values will change depending on distance. A daylight filter is built into the sensor.

• 5VDC operating voltage (recommended)
• 70mA supply current
• Optimal sensing distance: 0.125" (3mm)
• Step File

Use this bracket to secure the IR Range Sensor to the Studica structure.

• Step File

The IR Distance Sensor GP2Y0A21YK0F uses a beam of infrared light to reflect off an object to measure its distance. Because it uses triangulation of the beam of light to calculate the distance, it is able to provide consistent and reliable readings which are less sensitive to temperature variation or the object’s reflectivity. The sensor outputs an analog voltage corresponding to the distance of the object, and can easily be read using an inexpensive analog to digital converter (ADC) chip.

Includes 40cm I2C female to TJC8 female cable

• Step File

• Stable, accurate distance measurement
• High precision, blind spots (3cm) super close
• A full set of ranging process
• Step File
