Green Studica Solid Golf Ball

The Studica MD2 is a next-generation high performance Motor Controller Driver and Sensor Adapter with many added features to make it ready to use in your robot project. The included VNH5019ATR-E Motor Controller ICs are very robust with high current output and several important protection features. Many other I/O options have been incorporated into this design to make it extremely easy to interface to several different sensors.

Features,

• Includes 2 VNH5019 Motor Controller ICs,
  • 2 Enable Inputs, 2 direction inputs, one PWM input per channel up to 20Khz
  • Up to 12A Continuous output per channel, 30A peak current short ms duration
  • Under-voltage, over-voltage, reverse-voltage protection
  • Thermal Shutdown protection
  • Current Limit protection
  • Current Sense Output Proportional to Motor Current (approx. 140 mV/A)
  • Loss of Ground and Loss of Vcc Protection
  • Protection against short to Ground and short to Vcc

Specifications,

• 3V-compatible inputs
• Directly interfaces with myRIO MXP Port
• 8-16V DC Battery Input Terminal, J7, (GND, MTRS+ PWR)
• Jumper Selectable Current sense feedback from the VNH5019 Motor ICs, J12, J17
• Reverse Power LED Indicator
• FWD and REV Motor Direction LED Indicators
• 3 Servo Headers, J9, J10, J11, (SIG, SVDC, GND)
• 1 Parallax Ping Sensor Port, J13, (GND, VCC, DIO)
• 1 Sharp IR Port, J21, (AI0, VCC, GND)
• 1 LSB Port, J18, (VCC AI0, AI1, AI2, AI3, GND)
• 1 Nav-X Port, J19, (VCC, SDA, SCL, GND)
• 2 Encoder Ports, J22, J23, (VCC, ENCB, GND, ENCA)
• 1 I2C Port, J20, (NC, SCL, SDA)
• Built in 5V 3A voltage Regulator
• 3.3V Power Rail Header, J3, from myRIO
• 5V Power Rail Header, J4, from onboard regulator
• GND Rail Header, J6
• Separate Servo Power Input, J8 (SV+ PWR, GND)

The 90 Degree Bracket is perfect for connecting two channels pieces at 90 angle from each other. Each side is 48mm wide to fit perfectly on the channel. As with the other Studica Robotics building components, it has the common hole pattern which makes it easy to connect to other structure with very little or no additional machining required. You can easily connect to other channel, extrusions, bushings, bearing, mounting brackets and more so you can quickly assemble and disassemble robots and automated systems.

Specifications:

• Material - Anodized 6061-T6 Aluminum
• Thickness - 3mm
• Step File

This kit may be used with older structure and most sensors.  It includes everything required to connect to the collection and sensors. The only other electronic item required may be the SR-Pro Camera.

Includes,

• VMX Robotics Controller
• Titan Quad Motor Controller
• VMX Cable and Board Pack
• Titan Cable Pack
• Servo Power Block
• Analog Module
• PWM Cable Set
