Clover Motor Mount

This clear Polycarbonate Perforated Sheet is 152mm x 400mm x 1mm thick (Approx 6" x 15.75" x 1/32" thick) with 3.2mm (1/8" ) holes spaced 8mm apart.

The Maverick Motor with 50.9:1 planetary gearbox features a high‑torque reduction system engineered for demanding robotic and automation applications. Its 6mm hex output shaft ensures secure coupling with Studica‑compatible components and other hex‑based mechanical systems. Built on Studica’s industrial‑grade motor platform, this unit provides reliable, consistent performance suited for precision‑controlled, heavy‑load mechanisms.

- For clamping use the 76141 Motor Mount Clamp Kit or the 76137 Clover Motor Mount

The Studica Multi-Mode Smart Servo features all-steel gears and large amounts of torque. This angular programmable Servo can fill a variety of roles on your robot or project. In standard mode, it operates on a +/- 150-degree range. Using the Studica Smart Robot Servo Programmer (sold separately) the Multi-mode Smart Servo can be configured to run in continuous, standard, and custom angular mode. In continuous rotation mode, the servo will have proportional speed control based on the PWM signal that you send with your servo controller.


• Step File

Made from 3mm thick heavy 6061-T6 Aluminum, the Inside L Bracket is 42mm x 45mm and is used inside the U Channel or Low profile channel.As with the other Studica Robotics building components, it has the common hole pattern which makes it easy to connect to other structure with very little or no additional machining required. You can easily connect to other channel, extrusions, bushings, bearing, mounting brackets and more so you can quickly assemble and disassemble robots and automated systems.

Specifications:

• Material - Anodized 6061-T6 Aluminum
• Thickness - 3mm
• Step File

The 100mm Omni Wheel provides rotational and sideways 360° maneuverability.  Great for omni directional movement and rotation, easy direction control and tracking, and for fast turning,

The Servo Standard Front Mounting Bracket is one option to mount the Multi-Mode Smart Servo (75002) to the Studica building structure.

• Step File

The 100mm (4") Flex Wheel can be used for intake systems and conveyors.

Specifications:

• Diameter:   100mm (4")
• Axial width:  25mm
• Hub:  1/2" Inner Hex
• Inner Material: Molded Plastic in Yellow
• Outer Material: TPU Polyurethane in Orange
• Outer Material Durometer: 40A
• Weight: 0.038kg
• Step File
