M3 x 25mm Socket Head Cap Screw (pack of 50)

The Servo Power Block is a 6V, 60W power injector that provides proper power for RC Servos. It does not interfere with the signal, it will only replace the power to the servo with 6V.

Features,

• Built in DC-DC converter
• Over-current shutdown
• ESD protection

Specifications,

• Nominal Input Voltage: 12V
• Operational Voltage Range: 6.0V
• Number of Channels: 8
• Max Current for All Channels Combined: 10A
• Total Continuous Power: 60W
• Size: 70mm x 45mm x 16mm
• Step File

M3 x 12mm Socket Head Cap Screw (pack of 100), Zinc Plated.

• Step File

M3 x 6mm Socket Head Cap Screw (pack of 50), Zinc Plated.

Step file

M3 x 10mm Socket Head Cap Screw (pack of 100), Zinc Plated.

• Step File

• 42.0mm*42.0mm*11.3mm thick
• 16*M3*8.0mm thread
• M3 pass through holes
• SHCS sit flush
• Material - AL6061-T6
• Step File

Used to change motor to axle motion 90 degrees. This can be used in between the U-channel.

Specifications:

• Material: Steel
• Number of teeth: 30
• Set of 2 for 1-1 drives
• Step File

The Studica End Piece Plate is commonly fastened to the inside end of the U Channel. As with the other Studica Robotics building components, it has the common hole pattern which makes it easy to connect to other structure with very little or no additional machining required. You can easily connect to other channel, extrusions, bushings, bearing, mounting brackets and more so you can quickly assemble and disassemble robots and automated systems.

Specifications:

Material: 6061-T6 Aluminum

• Step File
