USB3.0 Video Cable, Type C to Type A , 1M

The Servo Horn 25T is made of anodized 6061-T6 Aluminum and is used with the Multi-Mode Smart Servo (75002) and the Studica building structure.

• Step File

Specifications:

• Material: 6061-T6 Aluminum
• Use with #25 Chain
• Number of teeth: 24
• Addendum - 52.04mm
• Dedendum - 45.25mm
• Pitch - 48.645
• Width - 2.5mm

Step file

The Studica Multi-Mode Smart Servo features all-steel gears and large amounts of torque. This angular programmable Servo can fill a variety of roles on your robot or project. In standard mode, it operates on a +/- 150-degree range. Using the Studica Smart Robot Servo Programmer (sold separately) the Multi-mode Smart Servo can be configured to run in continuous, standard, and custom angular mode. In continuous rotation mode, the servo will have proportional speed control based on the PWM signal that you send with your servo controller.


• Step File

Use the Dupont Single Pin - 4 wire - female to female cable with the Ultrasonic Distance Sensor

Specifications:

• Dupont Single Pin
• 4 wire
• female to female cable
• Length: 50cm
• Gauge: 22AWG

This set of 12 pieces includes,

• 2 x 20cm 22AWG Cables with Dupont TJC8 2.54mm 3 pin, female to female connectors
• 2 x 40cm 22AWG Cables with Dupont TJC8 2.54mm 3 pin, female to female connectors
• 2 x 60cm 22AWG Cables with Dupont TJC8 2.54mm 3 pin, female to female connectors
• 6 x 3pin Dupont male to male connectors

The Servo Standard Front Mounting Bracket is one option to mount the Multi-Mode Smart Servo (75002) to the Studica building structure.

• Step File

The Studica End Piece Plate is commonly fastened to the inside end of the U Channel. As with the other Studica Robotics building components, it has the common hole pattern which makes it easy to connect to other structure with very little or no additional machining required. You can easily connect to other channel, extrusions, bushings, bearing, mounting brackets and more so you can quickly assemble and disassemble robots and automated systems.

Specifications:

Material: 6061-T6 Aluminum

• Step File
