6mm Hex Shaft Flanged Bearing (12 pack)

This is the cable designed for the encoder that is pre-attached to the NeveRest Series of motors and gearmotors. It has a connector on the opposite end to directly interface with the REV Expansion Hub or the REV Control Hub.

2019 Update:

The 'a' version of this cable as the encoder channels swapped so that the encoder counts in the same direction as the output shaft spins. This simplifies the usage of the encoder with the various programming languages for FTC!

Specifications

• Length: 20 in.

The Studica Robotics 6mm Hex Shaft Low Profile Clamping Hub V2 is an ideal fit for our motors.

Step File

Precision Hub for Hex-Shaft Couplings

The Studica Robotics 6 mm Low Profile Hex Shaft Clamping Hub V2 is engineered to deliver a secure and compact coupling between your motor or drive shaft and wheels, sprockets, or other mechanical components. With its 6 mm hex-shaft ID and low profile form, it's ideal for tight-space and high-precision builds.  Made of aluminum, the Studica Robotics Clamping 6mm Hex Shaft Hub-V2 is used with our wheels.

Step File

The Studica Robotics 6mm Hex Shaft Face Bearing Block can be mounted on any channel and bracket allowing for a 6mm ID through hole for 6mm shafts (axles). The block has a permanently installed Standard Sealed Bearing and has 8 x M3 tapped through holes for easy mounting.

The Studica T-Slot 3030 V-Rail is available in 11 different lengths from 48mm to 1000mm. It is strong while light weight. It can be easily cut to your own custom size. It has a 14mm through hole that will fit the Studica 6mmID x 14mmOD Flanged Bearing or Bronze Bushing. It uses the M3 T-Slot Nut Hammer Head Series 20.  It also has four M3 threaded holes on each end. Use it as structure on infinite applications.

Specifcations,

• Material:  6061-T6 Aluminum
• Length: 96mm
• Deburred, polished, and anodized
• Step File

M3 x 8mm Stainless Steel Socket Head Cap Screw (pack of 100)

• Step File
