Robot Base Plate B (432mm x 288mm x 3mm)

The Studica Multi-Mode Smart Servo features all-steel gears and large amounts of torque. This angular programmable Servo can fill a variety of roles on your robot or project. In standard mode, it operates on a +/- 150-degree range. Using the Studica Smart Robot Servo Programmer (sold separately) the Multi-mode Smart Servo can be configured to run in continuous, standard, and custom angular mode. In continuous rotation mode, the servo will have proportional speed control based on the PWM signal that you send with your servo controller.


• Step File

The Studica T-Slot 3030 V-Rail is available in 11 different lengths from 48mm to 1000mm. It is strong while light weight. It can be easily cut to your own custom size. It has a 14mm through hole that will fit the Studica 6mmID x 14mmOD Flanged Bearing or Bronze Bushing. It uses the M3 T-Slot Nut Hammer Head Series 20.  It also has four M3 threaded holes on each end. Use it as structure on infinite applications.

Specifcations,

• Material:  6061-T6 Aluminum
• Length: 96mm
• Deburred, polished, and anodized
• Step File

The Studica Robotics 36-Tooth Hex Shaft Helical Bevel Gear 1:1 Set is designed to enhance motion control in robotics applications. This gear set, made of titanium-plated hardened steel features helical bevel gears with 36 teeth, optimized for use with 6mm hex shafts, providing a 1:1 gear ratio. Ideal for transmitting motion between perpendicular shafts, it ensures smooth and efficient power transfer in your robotic designs.

The Servo Horn 25T is made of anodized 6061-T6 Aluminum and is used with the Multi-Mode Smart Servo (75002) and the Studica building structure.

• Step File

The Maverick Motor with 50.9:1 planetary gearbox features a high‑torque reduction system engineered for demanding robotic and automation applications. Its 6mm hex output shaft ensures secure coupling with Studica‑compatible components and other hex‑based mechanical systems. Built on Studica’s industrial‑grade motor platform, this unit provides reliable, consistent performance suited for precision‑controlled, heavy‑load mechanisms.

- For clamping use the 76141 Motor Mount Clamp Kit or the 76137 Clover Motor Mount

The IR Distance Sensor GP2Y0A21YK0F uses a beam of infrared light to reflect off an object to measure its distance. Because it uses triangulation of the beam of light to calculate the distance, it is able to provide consistent and reliable readings which are less sensitive to temperature variation or the object’s reflectivity. The sensor outputs an analog voltage corresponding to the distance of the object, and can easily be read using an inexpensive analog to digital converter (ADC) chip.

Includes 40cm I2C female to TJC8 female cable

• Step File
