WS500 UAV Quadcopter Kit

Introducing The Mecanum Stack Robot - Autonomous Mobile Robotics Trainer by Studica Robotics with mecanum wheels, also includes the 3d Depth Camera and 360 Degree Lidar is a cutting-edge robotics trainer designed to ignite your passion for learning robotics like never before! This Trainer is a great value and its compact size is ideal for groups of two to three to participate in hands-on learning.

The Studica T-Slot 3030 V-Rail is available in 10 different lengths from 48mm to 1000mm. It is strong while light weight. It can be easily cut to your own custom size. It has a 14mm through hole that will fit the Studica 6mmID x 14mmOD Flanged Bearing or Bronze Bushing. It uses the M3 T-Slot Nut Hammer Head Series 20.  It also has four M3 threaded holes on each end. Use it as structure on infinite applications.

Specifcations,

• Material:  6061-T6 Aluminum
• Length: 48mm
• Weight: 0.126kg
• Deburred, polished, and anodized
• Step File

The Studica T-Slot 3030 V-Rail is available in 10 different lengths from 48mm to 1000mm. It is strong while light weight. It can be easily cut to your own custom size. It has a 14mm through hole that will fit the Studica 6mmID x 14mmOD Flanged Bearing or Bronze Bushing. It uses the M3 T-Slot Nut Hammer Head Series 20.  It also has four M3 threaded holes on each end. Use it as structure on infinite applications.

Specifcations,

• Material:  6061-T6 Aluminum
• Length: 144mm
• Weight: 0.38kg
• Deburred, polished, and anodized
• Step File

Our improved and  stronger 12-volt DC motor with 100 rpm and 708 oz-in. of torque. The motor features a built-in, high-resolution Hall effect encoder for precise motor control and comes with an encoder cable.

A 61:1 gearbox comes standard.

Output Counts per Revolution of Output Shaft (cpr) 1,464 pulses

The Studica Servo Hub Pro can be used with the Multi Mode Servo, Multi Mode Servo 200, or most servos with a 25 Tooth gear.

Specifcations:

• Spline: 25 Tooth, 3.8mm deep
• Height: 9mm
• OD: 30mm
• Material: 6061-T6 Aluminum
• Step File

The WorldSkills Autonomous Mobile Robotics Shanghai 2026 FULL Collection, by Studica, is the authorized collection that will be used at the WorldSkills Shanghai 2026 Autonomous Mobile Robotics Competition, 22-27 September 2026. This collection includes some of the items in the previous Lyon competition collection but has many new parts.

The collection includes everything you will need to complete one of four full functioning robots that will be able to compete at Shanghai 2026. As in the previous, you will be allowed to create 3D printed parts to make any additional parts needed. Includes the VMX Robotics Controller, electronics, accessories, motors, servos, mounts, U-Channel, mounting plates, flat brackets, irregular brackets, and flat beams. You'll also find gears, sprockets, pulleys, belts, axles, slides, rack & pinion, wheels, bushings, bearings, coupling, collars, spacers, screws, nuts, and standoffs. (Over 2,100 components).

The BASE collection is enough to build just the four base robots. (CAD files attached below). The FULL collection can build the four robots and provides extra parts for the robot OMS assemblies.

• Differential Drive Robot
• Differential Drive All-Terrain Robot
• Mecanum Robot
• X-Drive Robot

There are four other collections to choose from for Shanghai 2026,

1. #70212 - Worldskills Autonomous Mobile Robotics Shanghai 2026 BASE Collection

2. #70215 - WorldSkills Autonomous Mobile Robotics Shanghai Upgrade LYON to FULL Collection

3. #70216 - Worldskills Autonomous Mobile Robotics Shanghai Upgrade LYON to BASE Collection

Download the complete BOM

The WS500 Spares kit comes with replacement parts for the WS500 UAV Quadcopter Kit. It includes,

• Two WS500 Propeller Set (2CW and 2CCW)
• One WS500 Propeller Guard Set ( 2 black and 2 orange)
• One WS500 Landing Gear Set
