    Shanghai Accessory Kit

    $499.00

    The Shanghai Accessory Kit includes the following items. Many of the parts are already included in the Shanghai Collection, however some, highlighted in blue text, are not.

    Qty Product Part #
    1 Mecanum Wheel Set (2 left, 2 right, 100mm, w/6mm Hub)  76240
    2 Rack & Pinion Set (1 Rack, 1 Pinion, 2 Glides) 76170
    1 Linear Slide Kit, 250mm Slide and Block 72064
    2 432mm U-Channel 76010
    2 192mm U-Channel 76015
    4 30 Tooth Bevel Gear 1 to 1 (2 Pack) 76219-2
    1 Flange Bearing 6mm ID, 14mm OD, 15mm Flange (12 pack) 76302-12
    1 Collar 6mm ID D-Shaft, 12mm OD (6 pack) 76304-6
    1 Shaft Spacer Plastic 6mm ID x 10mm OD x 1mm L (24 pack) 76305-24
    1 Shaft Spacer Plastic 6mm ID x 10mm OD x 5mm L (12 pack) 76307-12
    1 M3 x 12mm Socket Head Cap Screw (pack of 100) 76202-100
    1 M3 x 10mm Button Head Cap Screw (pack of 50) 76203-50
    1 M3 Kep Nut (pack of 100) 76204-100
    1 48mm Standoff (12 pack) 76181-12
    2 Servo Mount Flat Plate 76145
    2 Servo Mount Offset Plate 76146
    2 Servo Horn 25T 76148
    2 6mm D-Shaft Servo Hub 25T 76149
    1 96mm Adjustable Flat Bracket (2 pack) 76083-2
    1 L Bracket (2 pack) 76087-2
    1 Inside L Bracket (2 pack) 76089-2
    1 144mm x 40mm Flat Bracket (2 pack) 76064-2
    1 96mm Flat Beam (2 pack) 76047-2
    2 96mm Square Beam 76107
    2 Multi-Mode Smart Servo 75002
    1 IR Range Sensor (10 cm to 80 cm) 40117
    1 IR Range Sensor Bracket 40118
    MFR Part #: 75103
    Availability: In stock
