WorldSkills Autonomous Mobile Robotics Shanghai 2026 BASE Collection

The Cube Orange+ Standard Set features a high-performance H7 processor and the 1090MHz ADS-B receiver from uAvionix. The Cube Orange+ has upgraded IMUs and the STM32H757 MCU. The autopilot can be set up to automatically avoid aircraft that are detected in an exclusion zone set by the pilot. Previously known as Pixhawk 2.1.

This product has the new Balanced Gyro (BG) sensors. Also, the Cube color is slightly darker now. For more details see the engineering change notice.

Designed as a more affordable replacement for the RealSense D435, the Studica 3D Depth Camera provides an accurate high-definition depth-sensing camera for mobile robotics and consumer electronic projects.

The WorldSkills Autonomous Mobile Robotics Shanghai 2026 FULL Collection, by Studica, is the authorized collection that will be used at the WorldSkills Shanghai 2026 Autonomous Mobile Robotics Competition, 22-27 September 2026. This collection includes some of the items in the previous Lyon competition collection but has many new parts.

The collection includes everything you will need to complete one of four full functioning robots that will be able to compete at Shanghai 2026. As in the previous, you will be allowed to create 3D printed parts to make any additional parts needed. Includes the VMX Robotics Controller, electronics, accessories, motors, servos, mounts, U-Channel, mounting plates, flat brackets, irregular brackets, and flat beams. You'll also find gears, sprockets, pulleys, belts, axles, slides, rack & pinion, wheels, bushings, bearings, coupling, collars, spacers, screws, nuts, and standoffs. (Over 2,100 components).

The BASE collection is enough to build just the four base robots. (CAD files attached below). The FULL collection can build the four robots and provides extra parts for the robot OMS assemblies.

• Differential Drive Robot
• Differential Drive All-Terrain Robot
• Mecanum Robot
• X-Drive Robot

There are four other collections to choose from for Shanghai 2026,

1. #70212 - Worldskills Autonomous Mobile Robotics Shanghai 2026 BASE Collection

2. #70215 - WorldSkills Autonomous Mobile Robotics Shanghai Upgrade LYON to FULL Collection

3. #70216 - Worldskills Autonomous Mobile Robotics Shanghai Upgrade LYON to BASE Collection

Download the complete BOM

This latest version of the VMX is the VMX2, a powerful robot controller,

• Enables Tele-op and autonomous control
• Programmable in Java, C++, Python, LabVIEW, and ROS
• Integrates the navX-IMU, a Linux based controller, Gigabit Ethernet, USB3 ports and built-in Wifi/Bluetooth.
• Can be used in a Robot Control System or Vision/Motion processor
• Supports Open CV, Tensor Flow, SLAM (Simultaneous Localization and Mapping
• Step Files

The VMX2 leverages five advanced key technology developments,

• Highly-integrated, inexpensive, WiFi-enabled, multi-core Linux computing platform with lots of USB IO for expansion
• 32-bit ARM Microcontrollers incorporating sophisticated I/O and digital communications engines
• Low-cost MEMs Inertial Measurement Units (IMUs)
• Powerful software providing rich libraries and tools for developing robot software in C++, Java
• CAN bus for high-speed, real-time communication between devices

The Studica VMX2 Technology Enables,

• Far richer development environments and tools
  • Because VMX2 is much more than a robot controller – it is a powerful, Linux-based desktop computing platform with network/monitor/keyboard/mouse support.
• Very powerful software features
  • State-of-the-art software development GUIs (e.g., VS Code) libraries and tools (drive-  train kinematics, path-planning, vision processing, autonomous navigation,   performance data acquisition/playback)
• Access to cutting-edge sensors (for use outside the competition)
  • VMX’s multitude of modern digital communications interfaces and Linux-based   operating system allow users to directly access most modern devices (e.g., Intel   RealSense tracking and depth cameras and LIDAR

The WorldSkills Autonomous Mobile Robotics Shanghai Upgrade LYON to BASE Collection, by Studica, is the authorized collection that can be used to train for the WorldSkills Shanghai 2026 Autonomous Mobile Robotics Competition, 22-27 September 2026. This collection includes all the essential components necessary to take robotics education and skills to the next level.

The BASE collection is enough to build just the four base robots. (CAD files attached below). The FULL collection can build the four robots and provides extra parts for the robot OMS assemblies.

• Differential Drive Robot
• Differential Drive All-Terrain Robot
• Mecanum Robot
• X-Drive Robot

The BASE collection is enough to build just the four base robots. (CAD files attached below). The FULL collection can build the four robots and provides extra parts for the robot OMS assemblies.

1. #70211 - WorldSkills Autonomous Mobile Robotics Shanghai 2026 FULL Collection

2. #70212 - Worldskills Autonomous Mobile Robotics Shanghai 2026 BASE Collection

3. #70215 - Worldskills Autonomous Mobile Robotics Shanghai Upgrade LYON to FULL Collection

Download the complete BOM

This kit includes,

• Wire Stripper for 12 and 10 AWG
• Wire Stripper for 24 - 16 AWG
• Powerpole Crimp Tool 15/30/45
• Dupont Crimper
• Insulated Terminal Ratchet Wire Crimping Tool
• Ferrule Crimping Tool

The Studica Robotics enhanced wheel Hex shaft hub kit is ideal for use with the Omni and Mecanum wheels for a strong axle hold. Used with Studica 100mm Omni wheel for a strong axel hold.

Specifications:

• Material: 6061-T6 Aluminum
• Color: Blue
• Includes clamp screws and screws and nuts for clamping to omni.
